Camera Specification:

LI-OX05C1S-MIPI-143H

OX05C1S 5MP Global Shutter RGB-IR Camera Module

$399.00

2 in stock

For high volume order, please email sales@leopardimaging.com

Categories: Robotics/Aviation, MIPI Camera Modules, I-PEX MIPI Camera Modules, Global Shutter MIPI Cameras, 5.0MP-OX05C, Platform Partners, OMNIVISION
Tags: , ,
OmniVision 1/2.525″ CMOS 5MP image sensor OX05C1S
Global shutter
4-lane MIPI CSI-2 interface
Active Pixels: 2592 (H) x 1944 (V)
Pixel Size: 2.2 x 2.2 μm
Focal Length: 2.42 ± 5% mm
FOV H: 143˚
Weight: ~ 9 g

Technical Inquires:

If you need to download the driver, please contact:support@leopardimaging.com

Autonomous Driving
Driver Monitoring System
Occupant Monitoring System
In-Cabin Monitoring System

Nvidia JETSON Camera Kit: Coming soon…

This camera is compatible with our USB 3.0 Tester and Nvidia Jetson platforms.

AGX Thor AGX Orin Orin NX Orin Nano AGX Xavier Xavier NX Nano TX2 TX1 USB3.0 Raspberry Pi5 RB3 Gen2 IQ-9075 EVK
N/A ✔ ✔ ✔ N/A N/A N/A N/A N/A ✔ N/A N/A N/A

For detailed driver: Click here
